Technical data
Power supply
Voltage supply 8-36V DC
Consumption 40-430mA depend on supply voltage and temperature
Consumption depends on supply voltage 0,104A at 8VDC
0,080A at 12VDC
0,051A at 24VDC
0,044A at 30VDC
0,040A at 36VDC
Allowed supply voltage drop-out: 100ms from min. 10V return to min. 8V
Battery voltage measurement tolerance 2 % at 24V
Hint:
For the supply voltage less than 7V the backlight of the display is switched off.
Short-term voltage drops (e.g. during the engine cranking) do not affect the operation at all.
Operating conditions
Operating temperature ID-Lite -20..+70
o
C
Operating temperature ID-Lite LT
#
-40..+70
o
C
Storage temperature -30..+80
o
C
Protection front panel IP65
Humidity 95% without condensation
Standard conformity
Low Voltage Directive EN 61010-1:95 +A1:97
Electromagnetic Compatibility EN 50081-1:94, EN 50081-2:96
EN 50082-1:99, EN 50082-2:97
Vibration 5 - 25 Hz, ±1,6mm
25 - 100 Hz, a = 4 g
Shocks a = 200 m/s
2
Low Temperature modification
LCD display limits controller operating temperature range to –20
o
C - + 70
o
C even if the other
electronic components work in wider temperature range.
Internal preheating foil is mounted in InteliDrive-Lite LT to extend display operational temperature
range.
Preheating starts at temperature below 5
o
C and preheating power depends on temperature and
power supply voltage.
Technical data
ID-Lite Standard Order code:ID-Lite-xxxxx
LT
Operating temperature -20
o
C..+70
o
C -40
o
C..+70
o
C
Storage temperature -30
o
C..+80
o
C -30
o
C..+80
o
C
Preheating foil increases controller current consumption
Preheating at ambient temperature Controller
consumption at
No preheating
0
o
C -20
o
C -40
o
C
12VDC 80 mA +75 mA +210 mA +325 mA
24VDC 51 mA +31 mA +100 mA +175 mA
