OFF mode
No start of the engine is possible. Outputs STARTER and FUEL SOLENOID are not energized.
No reaction if START,STOP buttons are pressed.
MAN mode
START – starts the engine.
STOP – stops the engine.
Hint:
The engine can run without load unlimited time.
The controller does not automatically stop the running engine in MAN mode.
The controller does not start the engine when binary input REM START/STOP is closed.
Start-stop sequence
MODE = MAN (Engine start/stop request is given by pressing buttons START and STOP )
MODE = AUT (Engine start/stop request is given by binary input REM START/STOP)
The start-up sequence can be interrupted in any time by coming stop request
Fuel solenoid is switched on with time advance of 1s fixed before starter motor is switched on.
Hint:
Threshold level for D+ input is 80% supply voltage; activation delay is 1s (to override short firings
during cranking – for example in cold conditions).
AUT mode
The controller does not respond to START, STOP buttons. Engine start/stop request is given by
binary input REM START/STOP.
Engine speed request is sourced from 3-PI function in AUT mode.
PI loop and Hysteresis comparator functions can be used both for Engine Load Limitation or any other
control function.
Engine without pickup operation
The RPM pickup input is ignored when Engine params: Gear teeth = 0. The engine running state is
then detected based on Engine params: Starting POil (not with AIN1 set to binary) or Engine
params: D+ function = ENABLED.
Engine run timer
MAN mode
Set the Engine params: Running Timer. Start engine in MAN mode by START button. Engine stops
itself after Running Timer is over. The STOP button cancels timer (forces cooling), the second STOP
cancels cooling (forces engine stop). Engine stays running when Running Timer = 0.
AUT mode
Engine starts and runs all the time when the LBI Rem start/stop is closed. Running Timer is activated
after Rem s/s is opened. To stop the engine the Rem start/stop has to be opened or controller
