Following dynamic cable parameters are important especially for maximal 200 meters CAN bus length
and 32 iS-COM units connected:
Nominal Velocity of Propagation min. 75% (max. 4,4 ns/m)
Wire crosscut min.0,25 mm
2
Maximal attenuation (at 1 MHz) 2 dB / 100m
Recommended Industrial Automation & Process Control Cables:
BELDEN (see http://www.belden.com):
• 3082A DeviceBus for Allen-Bradley DeviceNet
• 3083A DeviceBus for Allen-Bradley DeviceNet
• 3086A DeviceBus for Honeywell SDS
• 3087A DeviceBus for Honeywell SDS
• 3084A DeviceBus for Allen-Bradley DeviceNet
• 3085A DeviceBus for Allen-Bradley DeviceNet
• 3105A Paired EIA Industrial RS485 cable
LAPP CABLE (see http://www.lappcable.com)
• Unitronic BUS DeviceNet Trunk Cable
• Unitronic BUS DeviceNet Drop Cable
• Unitronic BUS CAN
• Unitronic-FD BUS P CAN UL/CSA
IL-NT RS232 (optional card)
Plug-in into ID-Lite controller COMMUNICATIN MODULE port.
Maximal distance 10m
Speed 19.2kBd (STD) 9.6kBd (MODBUS)
Recommend external converter:
ADVANTECH – ADAM 4520: RS232 to RS422/485 converter, DIN rail, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated.
Recommended internal converter:
ADVANTECH – PCL-745B or PCL745S : Dual port RS422/485 Interface card, automatic RS485 bus
supervision, no external data flow control signals, galvanic isolated
IL-NT RS232-485 (optional card)
Plug-in into ID-Lite controller COMMUNICATION MODULE port.
Maximal distance 10m (RS232), 1200m (RS485)
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog modem,
9.6 kBd digital modem, 57.6 kBd (MODBUS)
IL-NT S-USB (optional card)
Plug-in into ID-Lite controller COMMUNICATION MODULE port.
Maximal distance 5m
Maximum Speed Up to 57.6 kBd (DIRECT), 38.4kBd Analog modem,
9.6 kBd digital modem, 57.6 kBd (MODBUS)
Use only shielded A-B USB cables up to 5m length.
Recommend USB cable:
USB-LINK CABLE 1.8M – ComAp A-B USB cable.
To Next Page
