ComAp InteliDrive Lite User Manual

ID–Lite-2.0 User guide, ©ComAp – January 2011 53
ID-Lite-2.0 User guide.pdf
Wrn Engine Temp
Output closes if the water temperature warning alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Sd FuelLevel
Output closes if the Fuel level shutdown alarm activates.
Wrn FuelLevel
Output closes if the Fuel level warning alarm activates.
Common Wrn
Output closes when any warning alarm appears.
The output opens, if
• No warning alarm is active and
• FAULT RESET is pressed
Common Sd
Output closes when any shut-down alarm appears.
The output opens, if
• No sd alarm is active and
• FAULT RESET is pressed
Common Fls
Output closes when any sensor fail alarm appears.
The output opens, if
• No warning alarm is active and
• FAULT RESET is pressed
OFF mode
The output is closed, if OFF mode is selected.
MAN mode
The output is closed, if MAN mode is selected.
AUT mode
The output is closed, if AUT mode is selected.
ChrgAlternFail
Output closes if engine is running and D+ input not energized.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Hint:
Threshold level for D+ input is 80% supply voltage.
ServiceTime
Output closes if the ServiceTime alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
