The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Overspeed
Output closes if the engine over speed alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Underspeed
Output closes if the engine “Wrn Underspeed” or “Sd Underspeed” alarm activates i.e. when RPM is
below the Engine Protect: Underspeed or Engine params: Starting RPM limit.
The output opens, if
• “Wrn Underspeed” alarm is not active
• “Sd Underspeed” alarm is not active and
• FAULT RESET is pressed
Start failed
Output closes after the engine start-up fails.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Battery flat
Output closes when InteliDrive-Lite performs reset during start procedure (probably due to weak
battery).
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
V batt failed
Output closes when battery over/under voltage warning appears.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Sd Oil Press
Output closes if the oil pressure shutdown alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Wrn Oil Press
Output closes if the oil pressure warning alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
Sd Engine Temp
Output closes if the water temperature shutdown alarm activates.
The output opens, if
• alarm is not active and
• FAULT RESET is pressed
