InteliLite4 AMF20 Global Guide
103
Maximum Cranking Time (page
226), 1st attempt
STARTER (PAGE 501) or FUEL
SOLENOID (PAGE 477) off, STOP
SOLENOID (PAGE 502) on,
Cranking Fail Pause (page 226)
timer started
Crank pause
Maximum Cranking Time (page
226) elapsed, last attempt
STARTER (PAGE 501) or PRESTART
(PAGE 496) off
Shutdown
(Start fail)
all cranking attempts elapsed FUEL SOLENOID (PAGE 477) off,
STOP SOLENOID (PAGE 502) on
Shutdown
(Start fail)
Crank pause Cranking Fail Pause (page 226)
elapsed
STARTER (PAGE 501) or FUEL
SOLENOID (PAGE 477) on, STOP
SOLENOID (PAGE 502) off,
Maximum Cranking Time (page
226) counter started
Cranking
Starting Idle Time (page 235) elapsed Minimal Stabilization Time
(page 237) and Maximal
Stabilization Time (page 238)
counter started
Running
any shutdown condition FUEL SOLENOID (PAGE 477) off,
STOP SOLENOID (PAGE 502) on
Shutdown
Running Stop request READY TO LOAD (PAGE 498)
off,Cooling Time (page 240)
counter started
Cooling
RPM = 0 or any other shutdown
condition
READY TO LOAD (PAGE 498) off,
FUEL SOLENOID (PAGE 477) off
Shutdown
GCB CLOSE/OPEN (PAGE 480)
closed
Loaded
Loaded GCB CLOSE/OPEN (PAGE 480)
opened
Running
RPM = 0 or any other shutdown
condition
FUEL SOLENOID (PAGE 477) off,
STOP SOLENOID (PAGE 502) on,
READY TO LOAD (PAGE 498) off,
Shutdown
Cooling Cooling Time (page 240)
elapsed
FUEL SOLENOID (PAGE 477) off,
STOP SOLENOID (PAGE 502) on
Stop
RPM = 0 or any other shutdown
condition
FUEL SOLENOID (PAGE 477) off,
STOP SOLENOID (PAGE 502) on
Shutdown
Start request READY TO LOAD (PAGE 498) on Running
Stop RPM = 0, Oil pressure not
detected, Generator voltage
<10V, D+ not active
Ready
If at least one of engine running
indication is detected when Stop
Time (page 240) elapsed.
Stop (Stop
fail)
