InteliLite4 AMF20 Global Guide
504
Related FW 1.3.0 Related applications AMF,MRS
Comm object 1249
Description
The binary output depends on measured generator active power. Power is compared with generator
nominal active power with use of hysteresis and with delay of switch 1s.
When the measured active power is equal to or bigger than 5 % of Nominal Power (page 206) for 1 s
then the binary output is active.
When the measured active power is equal to or lower than 3 % of Nominal Power (page 206) for 1 s then
the binary output is inactive.
Supplying Load
6 back to Logical binary outputs alphabetically
LBO: V
Related FW 1.3.0 Related applications AMF,MRS
Comm object 38
Description
This logical binary output is activated at the beginning of start procedure together with PRESTART (PAGE
496) LBO. Ventilation output is deactivated when engine stops revolving.
Ventilation LBO is also deactivated immediately when EMERGENCY STOP (PAGE 448) (or E-Stop) is
activated or when controller is switched to OFF mode.
Note: The output is intended for control of an engine room ventilation fan, engine container ventilation
fan, container louvres or similar running gen-set technology.
Ventilation
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 2090
Description
This logical binary output is activated on falling edge of VENTILATION (PAGE 504) LBO (when engine stops).
The pulse duration is adjusted by Ventilation Pulse Time (page 255) setpoint.
Note: The output is intended for control of an engine room ventilation fan, engine container ventilation
fan, container louvres or similar running gen-set technology.
Ventilation Off Pulse
6 back to Logical binary outputs alphabetically
Related FW 1.3.0 Related applications AMF,MRS
Comm object 2089
Description
This logical binary output is activated on rising edge of VENTILATION (PAGE 504) LBO (at the begining of
prestart period). The pulse duration is adjusted by Ventilation Pulse Time (page 255) setpoint.
Ventilation On Pulse
