InteliNano-NT Plus, SW version 2.0.1.x, ©ComAp – July 2015
19
4.6.4 AMF application: Mono Phase
G
N L1 N N
L1
GENERATOR MAINS
L1 N
N
Figure 4.11
AMF APPLICATION MONO PHASE TERMINALS CONNECTION
Single-phase measurement – 1PH
Figure 4.12
MONOPHASE CONNECTION
