InteliVision 8
56
6 Features based on USB
6.1 Directory structure and names of files 56
6.2 Export of history 57
6.3 Export/import of trends 58
6.3.1 Continuously saving of trends 58
6.3.2 Single export of trends 59
6.3.3 Import of TRD file 60
6.4 Export of archive and InteliVision 8 firmware 60
6.5 USB as “login key” 61
6 back to Table of contents
InteliVision 8 display allows using USB stick as USB storage. The USB storage could be used in common way
like place where important data could be saved or as quick way how to log in.
InteliVision 8 is equipped by USB port on the back side, which automatically detects plug/unplug on of USB
storage.
When USB storage is connected to InteliVision 8 it is indicated by blue icon in the right side of upper status bar
Features based on USB (page 56). In opposite case the icon is missing.
During of USB storage operation the blue color of USB icon changes color according to type of operation. When
data is exported from InteliVision 8, the icon is red, when data is imported, the icon is green.
Image 6.1 USB stick connected icon
6.1 Directory structure and names of files
All files exported from IV8 are stored in specified location. Directory structure on USB storage is strictly
definedDirectory structure and names of files (page 56). If directory structure does not exist in connected
USB, it is automatically created during the first export of data from IV8 to USB.
If it is necessary directory structure on USB stick can be created also manually (e.g. in case of creating a file
with login information). It is not necessary to create manually whole directory structure according to Directory
structure and names of files (page 56)(e.g. only “InteliVision 8\Password” can be created), the missing
folders will be created automatically during first export of data.
