ComAp InteliVision 8 User Manual

InteliVision 8
95
11.5 Communication interface
RS232 Interface
Maximal distance 10m
Speed up to 57,6kBd
RS485 Interface
Galvanic separated
Maximal distance 1000m
Speed up to 57,6kBd
Only 1 IV8 is possible connect on RS485 (only 1 Master can be connected)
CANBus Interface
Galvanic separated
Maximal CAN bus lenght 200m Speed 250kBd
Nominal impedance 120Ω
Cable type twisted pair (shielded)
For other details see controllers installation guides (IGS-NT-2.6-Installation Guide.pdf and ID-DCU-
Industrial-2.9.pdf) and ID-Mobile-1.1 Reference Guide r1.pdf.
USB Slave
USB slave (for system administration only) is accessible without cover removal.
USB Master
USB Master is determined for features based on USB. See chapterFeatures based on USB (page 56).
11.6 Operating system
Windows CE 6.0 operating system
11.7 LCD display
8" color TFT display with resolution of 800 × 600 pixels
LCD display active area dimension 162x121,5mm
Pixel size 0.2025(W) x 0.2025(H) mm
Display lifetime at least 20.000h (display will be switched off when inactive)
Item Symbol Condition
Values
Unit Remark
Min. Typ. Max.
Viewing angle
(CR>10)
θL
θR
θT
θB
Φ=180°(9o’clock)
Φ=0°(3o’clock)
Φ=90°(12o’clock)
Φ=270°(6o’clock)
60
60
40
60
70
70
50
70
-
-
-
-
degree Note1
Contrast ratio CR Normal 400 500 - Note2
Luminance L θ=Φ=0° 300 350 - cd/m² Note3
