InteliVision 8
76
9.4.1 IGS-NT controllers and 4 InteliVisions 8 on CAN2
Up to 4 InteliVision 8 can be installed on CAN2 with using one from IGS-NT.
First two addresses Addr.1 and Addr.2 are possible to use directly as InteliVision 8 terminal address without
any special settings, in case that these addresses are not used with other compoment on CAN2 (e.g. IG-IB
etc.).
The third and the fourth InteliVision 8 use so called „Modem address” for connection on CAN2. InteliVision 8
shares these addresses with Modem. Each Modem address can be occupied either only with InteliVision 8 or
only with Modem. It is not possible to use them simultaneously.
If the third and fourth addresses have to be used by InteliVision 8, the addresses have to be enabled by the
appropriate setpoints - CanAddrSwitch1 and CanAddrSwitch2.
Note: There are Setpoints CanAddrSwitch1 and CanAddrSwitch2 in IGS-NT 2.4, which allow switching
between modem address and terminal IV8 address.
The setpoints are placed in Setpoints → Comms settings.
CanAddrSwitch1
Modem address 1 (default value)
InteliVision 8 - Terminal #3
CanAddrSwitch2
Modem address 2 (default value)
InteliVision 8 - Terminal #4
In summary, a user can decide if he uses max. 2 InteliVisions 8 and 2 modems on CAN2 bus or uses modem
addresses for connection of 2 additional InteliVisions 8 on CAN2 – totally he has 4 InteliVisions on CAN2.
9.4.2 ID-DCU Marine controller and up to 8 InteliVisions 8 on
CAN2
4 InteliVision on CAN2
Currently, the maximal number of the IV 8 displays has been increased up to 4 IV 8 with using one ID-DCU-
Marine controller on the same CAN2 bus or up to 8 InteliVisions 8 with using two ID-DCU-Marine controllers
separated by I-CR (Comap CAN repeater) on the same CAN2 bus see ID-DCU Marine controller and up to
8 InteliVisions 8 on CAN2 on page 76. This feature is supported from firmware version ID-DCU-Marine-1.7
or newer.
CAN addresses Addr.1, Addr.2 and Addr.4 are possible to use directly as InteliVision terminal address without
any settings. .
The fourth InteliVision 8 uses so called „Modem address” for connection on CAN2. InteliVision 8 shares this
address with Modem, but only one of them can use this address at one time (not possible to use them
simultaneously).
Addr.3 is configurable by setpoint 5thRemPan.
5thRemPan
ENABLE
(Addr.3 can be used by InteliVision 8)
DISABLE(default value)
(Addr.3 is used by Modem)
