InteliVision 8
92
11 Technical data
11.1 Power supply 92
11.2 Operating conditions 92
11.3 Climatic, mechanical and EMC standards 92
11.4 Dimensions and weight 94
11.5 Communication interface 95
11.6 Operating system 95
11.7 LCD display 95
6 back to Table of contents
The device is intended to be used in the engine room or on the engine directly.
11.1 Power supply
Value Controller IVDisplay
Voltage supply 8-36V DC 8-36V DC
Consumption depends on supply voltage
0,4A at 8VDC 1A at 8VDC
0,15A at 24VDC 0,35A at 24VDC
0,1A at 36VDC 0,25A at 36VDC
Power dissipation 9 W
11.2 Operating conditions
Operating temperature -20...+70°C
Storage temperature -30...+80°C
Flash memory data retention time 10 years
Protection front panel IP65
Humidity
95% without condensation
IEC/EN 60068-2-30
11.3 Climatic, mechanical and EMC standards
InteliVision 8 fulfill following standards:
CE Standard conformity
Low Voltage Directive: 2006/95/EC
EMC directive: 2004/108/EEC
