AVAILABLE OPTIONS FOR E.DO
55
Comau Robotics Product Instruction
6.2 e.DO Marker Holder
– What is the e.DO Marker Holder for?
– Safety requirements for e.DO Marker Holder use
– e.DO Marker Holder diagrams and drawings
– How to mount the e.DO Marker Holder on the e.DO Robot
– How to fix the marker on the e.DO Marker Holder
6.2.1 What is the e.DO Marker Holder for?
The e.DO Marker Holder is a tool specifically designed to be installed on the wrist of the
e.DO Robot.
The e.DO Marker Holder allows you to fix on the wrist of the e.DO Robot a felt-tip marker
and have e.DO write operations on flat surfaces.
The surfaces on which it is possible to write with the e.DO Marker Holder must be
horizontal and parallel to the floor.
Fig. 6.2 - e.DO Marker Holder - Overview
The e.DO Marker Holder can be mounted directly on the Robot flange, or used matching
it with the e.DO Gripper.
