Comelit VIP System - Chapter 3: System Preparation and Specifications; Connection Distances; Connection Distances from Power Supply Unit Art. 1395; Art. 1595 to External Unit; Connection Distances between External Unit and Switch Art. 1440

22
Chapter 3: System preparation and specications
Connection distances from power supply unit Art. 1395 / Art. 1595 to external unit
The connection distance varies depending on the port used on Switch Art. 1440.
Art. 1440
10 Mb
250 m
Art. 1440
100 Mb
120 m
Using the 10 Mb port
Using the 100 Mb port
The connection distance varies depending on the ports used on Switches Art. 1440.
Art. 1440
10 Mb
250 m
Art. 1440
10 Mb
Art. 1440
10 Mb
250 m
Art. 1440
100 Mb
Art. 1440
100 Mb
250 m
Art. 1440
10 Mb
Art. 1440
100 Mb
120 m
Art. 1440
100 Mb
Connection distances
Connection distances between external unit and Switch Art. 1440
Connection distances between 2 Switches Art. 1440
Art.1395 Art.1595
A Max
0,5 mm
2
(Ø 0,8 mm - AWG 20)
10 m 25 m
0,5 mm
2
(Ø 0,8 mm - AWG 20)
Comelit Art. 4576-4578
10 m 25 m
1 mm
2
(Ø 1,2 mm - AWG 17)
25 m 50 m
1 mm
2
(Ø 1,2 mm - AWG 17)
Comelit Art. 4577 / 4579
25 m 50 m
1 mm
2
(Ø 1,2 mm - AWG 17)
25 m 50 m
1,5 mm
2
(Ø 1,4 mm - AWG 15)
40 m 75 m
2,5 mm
2
(Ø 1,8 mm - AWG 13) 60 m 100 m
Art.1395
Art.1595
