Configuration 5
October 2013 GB 39 /80
1 Connect the potential-free contact, which is re-
quired for the function "Remote Start/Stop" to
the appropriate terminals (see wiring diagram).
This input is permanently programmed for the
"Remote Start / Stop" function.
2
Tap the <Settings> tab.
3
Tap the <Control...> button.
4
Press the <arrow keys> until the <Remote
Start Enabled> button appears.
5
Tap the button <Remote Start Enabled>.
–
The input mask "Remote Start Enabled" ap-
pears.
6
Tap button <On>.
The <Cancel> button can be used to cancel en-
abling of the remote start function. The previ-
ously active setting is used.
7
Tap the <OK> button.
✓
The function "Remote Start/Stop" is enabled.
–
The menu "Control" appears.
–
"On" is now displayed on the button <Re-
mote Start Enabled>.
–
Likewise it is indicated in the menu "Home"
that the function "Remote Start/Stop" is en-
abled.
–
The message "Attention:Start by Remote
Control..." appears on the display
Now the compressor can only be switched on and
off via the potential-free contact. The start and
stop buttons on the control panel no longer func-
tion, the <emergency-stop> button still functions.
Tapping the button <Off> in the menu "Remote
Start Enabled" allows the function "Remote Start/
Stop" to be deactivated again.
Remote start function after a power failure
After a power failure the remote switch must be
switched OFF and then ON again so that the com-
pressor starts.
If an automatic restart is desired after a power fail-
ure, this function must be activated accordingly
(see chapter "Setting automatic restart after a
power failure") and the remote switch must still be
set to "ON" when the power supply comes back on
line.
5.5.8 Remote Load and Off-Load (FS)
This function makes it possible to remotely switch
an FS compressor, e.g. from a control room, off
and on-load.
DANGER
In this operating mode, the compressor
may start up automatically at any time.
➯
Provide the compressor with warn-
ing signs.
➯
Keep the compressor room locked.
➯
Instruct personnel.
➯
Install the main switch according to
EN 60204 and attach a warning sign
to it.
NOTICE
Material damage
➯
Only potential-free contacts may be con-
nected to the terminal strip.
External voltages result in destruction of the
controller.
➯
The potential-free contacts must not be
more than 20 metres away from the termi-
nal strip.
If necessary, coupling relays must be fitted
in the switch cabinet.
Activating the function "Remote Load and
Off-Load"
1
Tap the <Settings> tab.
2
Tap the <Programmable Inputs and Out-
puts...> button.
3
Program a free input to "Enable Remote Load".
4
Program a further free input to "Remote Load".
As long as the function "Enable Remote Load"
is activated, the on-load/off-load command can
only be given via the remote load input. All internal
pressure setpoints are ignored. If the line pressure
exceeds the set compressor rated pressure due
to a permanent remote load signal by more than
0.5 bar, "Warning A606:Line Pressure high" is dis-
played. As long as warning "A606" is active, the
remote load input is deactivated.
