Foreword 1
October 2013 GB 3 /80
1 FOREWORD
1.1 About these operating
instructions
These operating instructions contain information
about controllers for fixed speed or variable speed
compressors and water- or air-cooled compres-
sors.
Special sections are labelled accordingly:
(FS) (fixed speed); for fixed speed compres-
sors
(RS) (regulated speed); for variable speed
compressors
(A) (air); for air-cooled compressors
(W) (water); for water-cooled compressors
All the inputs shown (parameters, settings and
configurations) are examples and do not apply to
a special application. They are not specific values
for your particular model of compressor.
The controller DELCOS XL is exclusively intended
for use with series DH compressors from Gardner
Denver.
These operating instructions are valid for the con-
troller DELCOS XL from software version DXL-
DH(RS)-1.0x.
Personnel Requirements
Only appointed personnel may work on the con-
troller and the compressor. The personnel have
been trained and briefed about the compressor.
The responsibilities of the personnel for operation,
maintenance and repair must be clearly defined.
The safe and hazard-aware working of the person-
nel must be checked regularly.
Personnel who are to be trained in, taught about
or instructed as part of a general training course,
must only work on the controller and compressor
under the constant supervision of an authorised
person.
If safety-relevant changes are made to compres-
sor or arise in its operating behaviour, the com-
pressor must be immediately shutdown and the
fault reported to the responsible post/person.
Faults, especially those that could impair safety,
must be immediately rectified. Otherwise the com-
pressor must not be operated.
Work on the electrical equipment may only be car-
ried out by a skilled electrician in accordance with
electrical engineering rules and regulations.
Reference documents
These operating instructions only describe the
DELCOS XL controller.
The operating instructions for the compressor
must be observed in addition to these operating in-
structions.
1.2 Intended use
The controller DELCOS XL installed is exclusively
intended for use with series DH compressors from
Gardner Denver.
1.3 Intentional misuse
Only changes authorised by Gardner Denver may
be carried out on the controller, both where soft-
ware and hardware are concerned.
1.4 Service
If you have any questions about or problems with
the compressor please contact your responsible
Gardner Denver agency.
The trained specialised personnel will ensure you
receive quick and proper assistance.
In case of queries
If you have a query or wish to make a spare parts
order, please specify the identification number and
year of manufacture on the name plate. Specifi-
cation of this data will ensure that you receive the
correct information and/or spare parts.
Your Gardner Denver Deutschland GmbH
agency
Please enter the details of your local Gardner
Denver agency in the following table.
Name:
Contact:
Address:
Phone
Fax
Email:
Chart 1-1: Local Gardner Denver agency
