4 Menus
16 / 80 GB October 2013
This graph shows the variation in the motor speed
over a specified period.
Contents of line graphs
X-axis; time axis
Y-axis; parameter value axis: the actual value is
displayed on the left alongside the graph
<Button> on the X-axis; scale the X-axis.
<Button> on the Y-axis; scale the Y-axis.
Scaling the Y-axis
Adjust the upper limit of the graph.
1 Tap the Y-axis <Upper button>.
–
The input menu "Trend Upper Limit" ap-
pears.
2 Tap the <Number buttons> to enter the Trend
Upper Limit.
3
Tap the <OK> button.
– The entries are accepted.
– The Y-axis scale is accordingly adjusted.
Data entry can be cancelled by tapping the button
<Cancel>.
Adjust the lower limit of the graph.
1 Tap the Y-axis <Lower button>.
–
The input menu "Trend Lower Limit" ap-
pears.
2 Tap the <Number buttons> to enter the Trend
Lower Limit.
3
Tap the <OK> button.
– The entries are accepted.
– The Y-axis scale is accordingly adjusted.
Data entry can be cancelled by tapping the button
<Cancel>.
Scaling the X-axis
Adjust the width of the graph.
1 Tap the X-axis <Button>.
–
The input menu "Trend Time Axis" appears.
2 Tap the desired option.
– The entries are accepted.
3
Tap the <OK> button.
– The X-axis scale is adjusted accordingly.
Data entry can be cancelled by tapping the button
<Cancel>.
4.5
Menu "Settings"
NOTE
All specific settings should be recorded, so that
if necessary they are available (e.g. for setting
up a replacement controller).
The settings can be entered in the "Adjustment
values" table in the appendix to these operating
instructions.
The menu "Settings" offers a selection of options
that can be individually adjusted so that the com-
pressor is used in accordance with requirements.
The menu is called via the tab <Settings>.
Hour meters...
.
Control...
Timer Control...
Programmable
Inputs and Outputs...
Communication...
Configuration...
Factory Settings...
SD-Card...
Select Menu
Settings
Control system
Water circuit...
Fig. 4-11: Menu "Settings"
The following sub-menus can be called from the
"Settings" menu:
"Hour Meters..."; to adjust the service intervals
"Control..."; to adjust the compressor operating
behaviour
"Timer Control..."; to set the date and time plus
time management
"Programmable Inputs and Outputs..."; to con-
figure functions and connected devices
"Communication..."; to configure RS485
interface(s)
"Configuration..."; to configure compressor
data, language, etc.
"Factory Settings..."; view for customer service
"SD-Card..."; switching-on and –off of data
recording
"Water circuit control..."; to set the cycle time
and the remaining time until the next water
change
