Troubleshooting 7
October 2013 GB 45 /80
Display Possible Cause Remedy
Fault VSD F038 .. F040
Earth fault at the VSD output. Check motor winding.
Carry out insulation test.
Fault VSD F041 .. F046
Short circuit at the VSD output. Check motor winding.
Carry out insulation test.
Fault VSD F064
Frequency converter (VSD) over-
load.
Check the differential pressure of
the fine separator.
Check the oil level.
Check the water content of the
oil.
Chart 7-2: Faults triggered by the frequency converter (VSD) (F000 - F399) (RS)
Faults triggered by the compressor (E400 - E495) (RS)
Display Possible Cause Remedy
Power failure. Find cause.
Voltage dip. Find cause.
Cabling damaged. Check cabling, repair if neces-
sary.
E400:
Power Supply Failure
Loose terminals. Check that all connecting termi-
nals and plugs are tight; retighten
if necessary.
Emergency-stop is /has been
activated.
Unlock the emergency-stop push-
button.
Emergency-stop pushbutton
defective.
Check emergency-stop pushbut-
ton, renew if necessary.
E401:
Emergency Stop Activated
Cabling damaged. Check cabling, repair if neces-
sary.
Drive motor has been started too
frequently.
Limit number of starts/hour.
Drive motor cooling defective. Check cooling air supply, improve
if necessary.
Power consumption too high. Check, find cause.
Faulty power supply. Check, find cause.
E402:
High Motor Temp. M1
Drive motor defective. Check drive motor, replace if nec-
essary.
Compressor outlet temperature
exceeded.
1)
Find cause.
Intake temperature too high. Check cooling air supply, improve
if necessary.
Inadequate cooling. Check cooling air or cooling
water supply, increase as neces-
sary.
E403
Compressor Disch. Temp.
Unit being operated with enclo-
sure open.
Close the enclosure.
Chart 7-3: Faults triggered by the compressor (E400 - E495) (RS)
