Taking a Look at the Computer
1-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: Carey Gregg Saved by: Carey Gregg Saved date: 04/27/00 1:45 PM
Part Number: 170706-002 File name: Ch01
Bottom Components
Bottom Components
Component Function
1
Speaker Produces sound.
2
Serial number Identifies computer; needed when you call
Compaq customer support.
3
Real-time clock battery Provides battery power to automatically
display the date and time.
4
Battery latches Releases the primary battery pack.
5
220-pin docking connector Connects the computer to a docking base.
6
Hard drive release latch Releases a hard drive from the hard drive
bay.
7
Hard drive security screw Secures hard drive in computer hard drive
bay.
8
Modem compartment Provides access to the internal modem
(modem models only).
