Comtech EF Data HPOD - Table A-7. ODPA X-Band 1:1 Redundancy Switch;Waveguide Kit (CEFD P;N KT;11387-1) Parts List

HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Appendix A MN/HPOD.IOM
A–20
Table A-7. ODPA X-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/11387-1) Parts List
ITEM QTY CEFD P/N DESCRIPTION
1 Not Used
2 Not Used
3 1 RF/CG-112/137INN Crossguide Coupler, 40 dB, Type N Connector,137-112
4 1 FP/WG11671-1 Waveguide, 1:1 Filter to TX
5 2 SW/WG-HAGS Switch, WR112G, +24V, Sealed, Standard Thread, Cold Temperature Rating
6 Not Used
7 2 FP/WG11305-1 Waveguide, 90 Degree H-Bend Transition
8 2 FP/WG11301-1 Waveguide, 90 Degree, CPRG-112
9 3 FP/WG11308-1 Waveguide, 90 Degree, H-Bend, CPRG-112
10 Not Used
11 1 RF/X-TERM850W Termination, Load, 850 Watt, CPRG112, with Crossguide Coupler, 40 dB
12 Not Used
13 14 GA/CPR112-R-F-C Gasket, Round, Full Thickness, CPR112
14 thru 19 Not Used
20 A/R HW/8-32HEXNUT Nut, Hex 8-32
21 A/R HW/8-FLT Washer, Flat S.S.
22 A/R HW/8-SPLIT Washer, Split S.S.
23 A/R HW/8-32X1/2SHCS Screw, Socket Cap
24 A/R HW/8-32X7/8SHCS Screw, Socket Head Cap, S.S.
25 A/R HW/SEM632X3/8PH Screw, Square Cone Pan Head Phillips S.S.
26 thru 30 Not Used
31 1 RF/ADAP-112-N Adapter, CPRG112 to "N"
32 1 RF/CG-112/137INN Coupler, Crossguide 40 dB N Type Connector
33 thru 54 Not Used
55 4 RF/N-TERM50M1
RF, 50Ω 1Watt. DC-8 GHz, Type N Male
A/R=UseAsRequired
