Table A-11. HPOD Ku-Band 1:1 Redundancy Switch/Waveguide Kit (CEFD P/N KT/12337-1) Parts List
ITEM QTY CEFD P/N DESCRIPTION
1 1 SW/WGS+28V-75SB Switch, Waveguide
2 1 RF/TERM75/350W Waveguide, Termination
3 1 FP/BR12338-1 Bracket, Mounting (ROHS)
4 1 FP/WG11934-1 Waveguide, Left
5 1 FP/WG11935-1 Waveguide, Right
6 2 HW/3/8SPRINGNUT Springnut
7 2 HW/3/8-FLT Washer, Flat
8 2 HW/3/8-SPLIT Washer, Split
9 2 HW/3/8-16X1BLT Bolt, Hex-Head
10 20 HW/6-FLT Washer, Flat
11 20 HW/6-SPLIT Washer, Split
12 4 HW/6-32X7/8SHCS Screw, Cap
13 16 HW/6-32X1/2SHCS Screw, Cap
14 2 GA/WR75-R-F-C Gasket, Full-Thickness
15 4 GA/WR75-R-H-C Gasket, Half-Thickness
16 1 FP/SP12360-1 Spacer (ROHS)
17 4 HW/4-FLT Washer, Flat
18 4 HW/4-SPLIT Washer, Split
19 4 HW/440X3/8SHCS Screw





