HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Appendix C MN/HPOD.IOM
C–3
C.2.2 Installing the New Power Supply
Tore‐installthepowersupply:
Step Task
1
Visually inspect the exposed SSPA heat sink for any debris/ blockage. Use compressed air to
clear/clean if needed.
2
Visually inspect both the SSPA and power supply connector for damage/cleanliness. Correct
and/or clean as required.
3 Inspect the gasket for damage. Replace as required
4
Place supply on SSPA, ensuring the guide pins and connection are properly aligned. Gently
press to engage the connector.
5 Tighten the four captive fasteners where indicated previously in Figure C-1.
Be sure to use an appropriate screwdriver, such as the one provided with the
SSPA, to avoid damaging the fasteners.
