HPOD C, X-, or Ku-Band High-Power Outdoor Amplifier Revision 6
Ethernet-based Remote Product Management MN/HPOD.IOM
4–2
4.2 Ethernet Management Interface Protocols
TheuserPCfacilitatesaccesstoEthernet‐basedremotemonitorandcontrol(M&C)oftheHPOD
throughthreeseparatelyoperatedprotocols:
• Simple Network Management Protocol (SNMP). This non‐secure interface requires a
user‐supplied Network Management System (NMS) and a user‐supplied Management
InformationBase(MIB)FileBrowser.
• Telnet Interface.Thisnon‐sec
ureinterfacerequires useofthe userPC’sCommand‐line
interface,orauser‐suppliedterminalemulationprogramsuchasHyperTerminal.
• HPOD Web Server (HTTP) Interface. This non‐secure interface requires a compatible
user‐suppliedwebbrowsersuchasInternetExplorer.
4.3 SNMP Interface
TheSimpleNetworkMa nag eme ntProtocol(SNMP)isanIn te rnet‐standardprotocolformanaging
devicesonIPnetworks.AnSNMP‐managednetworkconsistsofthreekeycomponents:
• Themanageddevice.ThisincludestheHPOD.
• The SNMP Agent. This is thesoftware that runs on theHPOD. The HPOD SNMP Agent
supportsbothSNMPv1andSNMPv2c.
• Theuser‐suppliedNetworkManagementSystem(NMS).Thisisthesoftwarethatruns
onthemanager.
4.3.1 Management Information Base (MIB) Files
ThefollowingMIBfilesareassociatedwiththeHPOD:
MIB File/Name (where ‘x’
is revision letter)
Description
FW-0020546x.mib
ComtechEFData Root
MIB file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data HPOD
products (PSx) and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFData(6247)
Module: ComtechEFData
FW-0020547x.mib
HPOD MIB file
MIB file consists of all of the OIDs for management of the HPOD functions
FW-0020548x.mib
HPOD Traps MIB file
Trap MIB file is provided for SNMPv1 traps common for HPOD.
