HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
External Connectors and Pinouts MN/HPOD.IOM
2–8
2.5.2 J6 | COM1 Connector
TheJ6|COM1DiscreteControlconnectoristheprimaryinputforcontrollingandmonitoring
theSSPA.Itisa19‐pincircularconnector,typeMS3112E14‐19S.Thepinoutspecificationis
showninTable2‐6.
Mati
ngconnector:ITT:KPT06J14‐19PorMS3116J14‐19P.
Table 2-6. J6 | COM1 Connector Pinout
Pin Name Description
A RS485_+RX
B RS485_-RX
C RS485_+TX
D RS485_-TX
E RS232_RD
F Ethernet TX+
G RS232_TD
H Ethernet TX-
J Aux_Out Not for customer use
K SumFLT_COM
L SumFLT_NO Open when faulted, else tied to Pin K.
M SumFLT_NC When faulted, tied to Pin K, else open.
N GND
P ONLINE_Status Not for customer use
R +24V Not for customer use
S Mute Control SSPA will be muted if this pin is grounded
T Minor_FLT_COM Reserved for future use
U Ethernet RX-
V Ethernet RX+
2.5.3 J8 | INPUT SAMPLE Connector
The J8 | INPUT SAMPLE port connector is a Type ‘N’ female. It provides a nominal –20 dB
sample of the input signal. A calibrati on label is provided near the connector that shows the
actualcouplingvaluesvs.frequency.
2.5.4 J9 | OUTPUT SAMPLE Connector
The J9 | OUTPUT SAMPLE port connector is a Type ‘N’ female. It provides a nominal‐40 dB
sample of the output signal. A calibration label is provided near the connector that shows the
actualcouplingvaluesvs.frequency.
