4.5.3 Web Server Interface – Operational Features
4.5.3.1 Navigation
Navigationtabs arelocatedatthetopof eachpage. Afteryouclicka
navigationtab,itsnestedpagehyperlinksappear.


Thismanualshowspagenavigationandhyperlinkselectionintheformat‘Top‐LevelNavigation
Tab|NestedPageHyperlink.’Forexample:‘Home|Support’isinterpretedtomean“firstclick
thetop‐level‘Home’navigationtab;th
en,clickthenested‘Support’pagehyperlink.”
4.5.3.2 Page Sections
Each page features one or more sections. The title at the upper‐left
cornerofeachpageorpagesectionindicatesitsoperationalfeatures.
Eachsectioncanfeaturee ditablefields,actionbuttons,andread‐only
displaysthatarespecifictothatsection.

Thismanual explainsthe purposeandoperationforeachwebpageon aper‐p
age,per‐section
basis.
4.5.3.3 Action Buttons
ActionbuttonsareimportantintheWebServerInterface.Clickan
actionbuttontodooneofthesetasks:

• Reset changedparameterstoremoveunsavedchanges.

• Permanentlysavechanges.

• Refreshthepagewithcurrentdata.

Ifyou editafield,makesuretoclicktheactionbu
ttonbeforeyouleavethepage.
Ifyougotoanotherpagewithoutfirstclickingtheactionbutton,yourchangesare
not
saved.
4.5.3.4 Drop-down Lists
A drop‐down list lets you choose from a list of selections. Left‐click
the drop‐downbutton to open thelist. Then, left‐click on anitemto
selectthatchoice.

