Table A-9. HPOD C-Band Offline Unit Termination Bypass Waveguide Kit (CEFD P/N KT-0020523) Parts List
ITEM QTY CEFD P/N DESCRIPTION
1 1 FP/BR12242-1 Bracket, Mount (ROHS)
2 1 SW/WG-3NFAS-COLD Switch, CPR 137
3 1 FP/WG10359-1 Waveguide
4 1 RF/CG-137-40-N Crossguide, WR 137
5 1 FP/5683 Waveguide Adapter
6 1 FP-0020546 Waveguide, CPRG 137
7 6 CB/CX50NMALE Connector, CN-50-OHM, Type ‘N’, Male
8 56 HW/10-FLT Washer, #10 Flat
9 48 HW/10-SPLIT Lock Washer, #10 Split
10 2 GA/CPR137-R-F-C Gasket, CPR 137, Full Height
11 5 GA/CPR137-R-H-C Gasket, CPR 137, Half Height
12 40 HW/10-32X5/8SHC Screw, Socket Head #10-32 x 5/8 LG
13 8 HW/10-32HEXNUT Hex Nut,3/8
14 8 HW/10-32X3/4SH Screw, Socket Head #10-32 x 3/4 LG
15 2 HW/3/8SPRINGNUT Spring Nut, 3/8
16 2 HW/3/8-FLT Washer, Flat, 3/8
17 2 HW/3/8-SPLIT Lock Washer, Split, 3/8
18 2 HW/3/8-16X1BLT Bolt, Hex Head, 3/8-16 x 1” LG







