2.3 RF Signal Interface Connector Group
2.3.1 J1 | RF IN Connector
TheJ1|RFIN(Input)connectorisaType‘N’female .Typicalinputlevels(‐30dBm)dependon
desired output power and unit attenuation. To prevent damage to the HPOD SSPA, RF input
levelsshouldnotexceed+15dBm.
2.3.2 J2 | RF OUT Connector
For safety reasons, never look directly into the waveguide output.

TheJ2 |RF OUT (Output)connector isa waveguideinterface. Theflangethat isused depends
onthefrequencyrangeoftheunit.

Table 2-2. J2 | RF OUT Waveguide Output Flange
Unit Frequency Band Waveguide Flange
C CPR137G
X CPR112G
Ku WR75G
