1.4 Specifications
Output C-Band X-Band Ku-Band
Frequency 5.850 GHz -to-6.425 GHz 7.9 GHz-to-8.4 GHz
14.0 GHz -to-14.5 GHz
(
Standard
)
13.75 GHz -to-14.5 GHz
(
Optional
)
Available Power: Outputs
P1dB (Psat), Watts
(See Note)
200
(
250
)
175
(
200
)
80
(
100
)
250
(
300
)
200
(
250
)
100
(
125
)
350
(
400
)
282
(
350
)
Phase Combined Systems
P1dB (Psat ), Watts
(See Note)
400
(
500
)
350
(
400
)
160
(
200
)
500
(
600
)
400
(
500
)
200(250)
700
(
800
)
550
(
700
)
Note: P1dB over all temp/frequencies, Psat typ.
Connector
CPR-137G Wave
g
uide CPR-112G Wave
g
uide
WR75G Waveguide
Mute -60 dBc
Impedance 50
VSWR 1.25:1 Maximum
Gain C-Band X-Band Ku-Band
Linear 70 dB min, 75 dB typical 65 dB min, 70 dB typical
Adjust 20 dB in 0,25 dB steps
Full Band
± 1.0 dB
with BUC option ± 1.5 dB
Per 40 MHz
± 0.25 dB
with BUC option ± 0.30 dB
-40 to +55°C ± 1.0 dB
with BUC option ± 1.5 dB
Third Order Intermodulation
Products
-30 dBc t
y
pical, -25 dBc max
@
3 dB total back-off from rated P1dB
(
two tones, f = 1 MHz
)
AM to PM Conversion
2° t
yp
ical, 3.5° maximum at rated out
p
ut
Group Delay (per 40 MHz)
Linear ± 0.03 ns/MHz
Parabolic ± 0.003 ns/MHz
2
Ripple ± 1.0 ns peak to peak
Spurious C-Band X-Band Ku-Band
Second Harmonic -60 dB dBc max @ 1 dB below rated output
Optional BUC LO Leakage -20 dBm






