HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
Introduction MN/HPOD.IOM
1–8
Input
Impedance 50
Noise Figure
8 dB t
y
pical, 10 dB maximum
@
maximum
g
ain
(
15 dB for HPOD Ku-Band
)
with BUC Option 25 dB
VSWR
1.25:1 Maximum
with BUC Option 1.50:1 Maximum
Connector Type ‘N’
Sample Ports
Output Sample Type N, 50, -40 dBc nominal
Input Sample
T
y
pe N, 50, -20 dBc nominal
Remote Control
COM Port
EIA-485 or EIA-232
Alarms
Summary Fault
Form C
Environmental
Operating Temp.
-40° to +55°C
(
-40° to 131°F
)
Non-operating Temp.
-50° to +75°C
(
-58° to 167°F
)
Operating Humidity
0% to 100% condensin
g
Altitude
10,000 ft above sea level
(
derated 2°C/ 1000 ft AMSL
)
Power Requirements
C-Band X-Band Ku-Band
(Typical)180 to 264 VAC, 47 Hz to 63 Hz
Ph
y
sical
Dimensions
26.77L x 17.88W x 11.49H inches
(
67.99L x 45.41W x 29.18H cm
)
Weight
75 lbs
(
34 k
g)
nominal
Available Options
O
p
tional BUC



