HPOD C-, X-, Ku-Band High-Power Outdoor Amplifier Revision 6
External Connectors and Pinouts MN/HPOD.IOM
2–5
2.4 Ground and Power Connection Group
2.4.1 Ground Connection
AnM4studisprovidedforconnectingacommonchassisgroundamongequipment.
2.4.2 J3 | AC IN Connector (AC Power Main)
Before applying AC power to the unit, make sure the waveguide output of the
amplifier is properly loaded or terminated. Failure to do so could lead to
equipment damage and excessive RF radiation levels.

Theprimepowerinputrequirementsare:

• 180to264VAC

• 47to63Hz

• Thepowersupplyispowerfactorcorrected.Thetotalpowerrequiredfromtheprime
powersupplydependsonthemodelused.Pleaserefertotherespectivedatasheets.

TheJ3|AC INACprimepowerinpu
tconnectorisa3‐pincircularconnector, typeCA3102E20‐
19PB FMLB A. Ground Pin ‘A’ is of the first make/last break type. A mating connector
(CA3106E20‐19SB) is provided. The pinout specifications for J3 and its mate are provided in
Table2‐3.

Table 2-3. J3 | AC IN Connector Pinout
Pin Description
A Ground
B L2
C L1

