UGE048/1103 CSC Combination Puller/Cutter
I
NTRODUCTION 1-5
● The emergency stop (E-stop) button is locat-
ed on the control panel on top of the upper
belt guard at the upstream end. Pressing
either of these disconnects power to the
entire unit. The E-stop must be physically
pulled up to reset the switch and start the
combination puller/cutter again.
● When the knife guard is opened, the knife
guard switch stops the cutter.
● Two proximity safety switches prevent cutter
operation unless the cutter bushings are in
place.
● The Stop button on the cutter control acti-
vates a circuit that stops the knife.
ATTENTION:
READ THIS SO NO
ONE GETS HURT
