Conair CSC - Checking the Belt Gap

CSC Combination Puller/Cutter UGE048/1103
5-16 MAINTENANCE
The optional Pneumatic Upper Belt Actuator can also be used
to position the upper belt. Refer to Appendix E for more infor-
mation.
Place the handwheel on the right threaded rod
and turn to move the lower belt up and down.
2
CHECKING THE
BELT GAP
C
ONTINUED
