CSC Combination Puller/Cutter UGE048/1103
3-10 INSTALLATION
Turn the main power disconnect to the off
position.
Remove the upper and lower belt guards:
● Remove the screws attaching guards to unit
(four each: top, bottom, front and rear).
● Disconnect the safety cable (on the upper guard).
● Lift off and remove guard.
ADJUSTING
BELT TENSION
1
2
Check belt tension. Use a tension-measuring tool.
Belts should be just tight enough to prevent slipping,
and the gap between the upper and lower belts should be
even across the width of the belt. NOTE: Loose
belts result in belt and product slippage; over-tightened
belts result in distorted product and can lead to prema-
ture bearing failure.
3
Continued
To Next Page
