The Conair CSC Combination Puller/Cutter pulls small- to
medium-sized extruded products through sizing and/or cooling
tanks and cuts the product to lengths. Since the puller and cut-
ter are mounted on the same chassis, alignment problems are
minimized.
The puller portion's direct AC drive system offers extremely
good speed control, which can be further improved by using
an optional servo motor. Different puller belt materials opti-
mize performance with different types of extruded materials.
The cutter portion utilizes a position-controlled servo motor.
CSC units achieve park position repeatability less than 0.1
millisecond.
Combination Puller/Cutter are available in several sizes:
WHAT IS THE
COMBINATION
PULLER/
C
UTTER?
CSC Combination Puller/Cutter UGE048/1103
2-2 DESCRIPTION
Puller section Cutter section
Combination Belt Width Traction Cutting
Model (+/- 3/8 inch) Length Capacity
320CSC2 3 inch 20 inch 2 inch
320CSC2L 3 inch 20 inch 1.25 inch
426CSC2 4 inch 26 inch 2 inch
426CSC2L 4 inch 26 inch 1.25 inch
426CSC3 4 inch 26 inch 3 inch
426CSC3L 4 inch 26 inch 2.25 inch
320CSC3 3 inch 20 inch 3 inch
320CSC3L 3 inch 20 inch 2.25 inch
426CSC4 4 inch 26 inch 4 inch
426CSC4L 4 inch 26 inch 3.25 inch
