CLEANING THE
LUBRICATION
TRAY
CSC Combination Puller/Cutter UGE048/1103
5-8 MAINTENANCE
The lubrication tray is built into the cutter assembly as a sim-
ple method of applying lubrication to your blade during cut-
ting cycles. Depending on cut rate and type of material and
lubrication, the area will need to be cleaned on a regular basis
and the lubricant replaced. Open the knife guard and, using a
shop vac or other similar equipment, remove all liquid and
solids from the cutting chamber and around the bushings.
Replace the lubricant. For more information, see Blade and
Bushing Lubrication, Appendix D.
L
UBRICATING
THE
SLIDE RAIL
Check the shafts on the slide rail system. Even though these
shafts are stainless steel, it is recommended that a light oil
(WD-40 or similar) be applied to the shafts as needed. Wipe
off any excess.
Lubricant Tray
