Conair Combination Puller/Cutters can process extrudable
plastics and rubber both on- and off-line. Other extrudable
materials-foods, ceramics, magnets, soaps, etc.-may also be
processed depending on specific application requirements.
Combination puller/cutters are available with different puller
sizes (3, 4 inch widths with traction lengths of 20, 26) and dif-
ferent cutting capacities (2, 3, 4, and 5 inches) to suit your
specific needs. The cutter servo motor size and cutter head
material may also be optimized for specific applications.
While the standard orientation is right-to-left, combination
puller cutters can also be made with a left-to-right orientation
(see Specifications, Section 2). (The illustrations in this User
Guide represent the standard right-to left configuration.)
CSC cutters are limited to a specific range of product sizes
based on each unit's cutting capacity. CSC cutters can operate
over a range of speeds (depending on which options are
included.) See Specifications, Section 2.
Different materials, line speeds, temperatures and material
cross-sections can result in different cutting torques. If you are
changing any of these parameters, consult your Conair service
personnel to be sure your equipment can handle the changes.
UGE048/1103 CSC Combination Puller/Cutter
D
ESCRIPTION 2-3
TYPICAL
APPLICATIONS
LIMITATIONS
● Because the maximum distance between the puller
and cutter is only six inches, the combination puller/
cutter is not suitable for larger rigid extruded parts.
● The unit is limited by the traction length (the length
over which the extrudate is in contact with the puller
belts), which is fixed for a particular model.
● The outer surface of the puller belt material will
affect performance. Softer (low durometer) materials
provide good 'grab', but will wear more quickly, and
may tear if the belt jams. Harder materials last
longer, but may not grab the extrudate properly.
Contact Conair for specific belt material recommendations for
your product.
