UGE048/1103 CSC Combination Puller/Cutter
I
NSTALLATION 3-9
Slide the upstream bushing into position, posi-
tioning it up to but not touching the blade. Use the feeler
gauge.
Tighten the set screw against the flat side of the
bushing to hold the bushing in position.
Rotate the cutter head by hand to make sure the
bushings did not move, and the the blade still passes
through the gap between the bushings.
4
5
6
MOUNTING THE
CUTTER
BUSHINGS
CONTINUED
To Next Page
