Conair CSC - ADJUSTING THE PNEUMATIC UPPER BELT ACTUATOR

UGE048/1103 PNEUMATIC UPPER BELT ACTUATOR
You can adjust the opening and closing speed of the air cylin-
der assembly that operates the upper belt boom assembly by
adjusting (lifting and turning) the air regulator handle.
ADJUSTING THE
PNEUMATIC
U
PPER BELT
ACTUATOR
Handle
APPENDIX G-2
