START-UP
PREPARATIONS
OPERATION 4-33
UGE048/1103 CSC Combination Puller/Cutter
If you have not already done so, perform daily maintenance
check, power up the puller/cutter, select cutting mode and
blade speed and make a test cut to check cut quality.
Use the slide system to move the cutter as far from the puller
as possible:
Loosen the turnbuckle at the downstream end of the
puller/cutter by turning 1-2 turns clockwise.
Slide the cutter as far downstream as it will go.
Tighten the turnbuckle
by turning it counterclock-
wise.
1
2
3
Locate puller on the extrusion line with the floor
support pads adjusted to the product centerline.
Note: Never operate belt puller on casters only.
Be sure power supply matches specified belt
puller power before connecting. If unsure, please do not
hesitate to call for service.
Adjust the belt puller entrance guide rolls to insure
consistent product guidance.
Adjust the belt opening to allow consistent traction to
the product without deformation.
1
3
2
WARNING: Improper installation,
operation, or servicing may result in
equipment damage or personal
injury.
This equipment should only be installed,
adjusted, and serviced by qualified technical
personnel who are familiar with the construc-
tion, operation, and potential hazards of this
type of machine.
All wiring, disconnects, and fuses should be
installed by qualified electrical technicians in
accordance with electrical codes in your
region. Always maintain a safe ground. Do not
operate the equipment at power levels other
than what is specified on the machine serial
tag and data plate.
Continued
To Next Page
