CONFIGURATION
5
1.4. GPRS/UMTS status
The industrial router XR5i v2 is not availability item GPRS/UMTS status.
GPRS menu item contains actual information about GPRS/UMTS connections.
Item Description
PLMN Code of operator
Cell The cell to which the router is connected
Channel The channel on which the router communicates
Level The signal quality of the selected cell
Neighbours Signal quality of neighboring hearing cells
Uptime Time to establish PPP connection
Table 4: Description of GSM information item
If the neighbor cell is highlighted in red, risk of often switching between neighbor and
actual cells.
The next section of this window displays information about the quality
of the GPRS/UMTS connection in each period.
Period Definition of the period
Today Today from 0:00 to 23:59
Yesterday Yesterday from 0:00 to 23:59
This week This week from Monday 0:00 to Sunday 23:59
Last week Last week from Monday 0:00 to Sunday 23:59
This period This accounting period. The interval must be set in the GPRS
Configuration
Last period Last accounting period. The interval must be set in the GPRS
Configuration
Table 5: Description of period
Item Description
Level Min. Minimal signal strength
Level Avg. Average signal strength
Level Max. Maximal signal strength
Cells Number of switch between cells
Availability Availability of PPP connection
Table 6: Description of GSM statistic
Availability is information in percentage, that is calculated us ration of PPP connect
time and router power on time.
After you place your cursor on the maximum or minimum signal strength, will show
the last time when the signal strength reaching the router.
In the middle part of window is shows information about transferred data and number
of connection both SIM card, for each period
Item Description
RX data Total volume of received data
TX data The total volume of data sent
Connections Number of PPP connection establishment
Table 7: Description of GSM traffic
