USED SYMBOLS

Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic

Manual issued in CZ, 12/15/2011

Used symbols

Danger – important notice, which may have an influence on the user’s safety or the function

of the device.

Attention – notice on possible problems, which can arise in specific cases.

Information, notice – information, which contains useful advice or special interest.

Firmware version

Actual version of firmware is 3.0.1 (26.9.2011).

GPL license

Source codes under GPL license are available free of charge by sending an email

to info@conel.cz

Routers version

Properties and settings of router associated with the GSM connection is not available

in industrial router XR5i v2.

PPPoE configuration item is only available on the industrial router XR5i v2, used to set

the PPPoE connection over Ethernet.

Declared quality system

ISO 9001
