CONFIGURATION
41
1.20. SNMP configuration
To enter the SNMP Configuration it is possible with SNMP agent ver.1 configuration
which sends information about the router, eventually about the status of the expansion port
CNT or M-BUS.
SNMP (Simple Network Management Protocol) provides status information
about network elements such as routers or end computers.
Item Description
Community Password for access to the SNMP agent.
Contact Person who manages the router together with information how to contact
this person.
Name Designation of the router.
Location Placing of the router.
Table 39: SNMP configuration
By choosing Enable I/O extension it is possible to monitor binary inputs I/O
on the router.
By choosing Enable XC-CNT extension it is possible to monitor the expansion port
CNT inputs and outputs status.
By choosing Enable M-BUS extension and enter the Baudrate, Parity and Stop Bits
it is possible to monitor the meter status connected to the expansion port M-BUS status.
Item Description
Baudrate
Communication speed.
Parity
Control parity bit:
• none – Data will be sent without parity.
• even – Data will be sent with even parity.
• odd - Data will be sent with odd parity.
Stop Bits
Number of stop bit.
Table 40: SNMP configuration
Parameters Enable XC-CNT extension and Enable M-BUS extension can not be
checked together.
