1.11. PPPoE configuration
PPPoE configuration item is available only on the industrial router XR5i v2.
PPPoE for industrial router works in client mode. Router using connection
to the PPPoE server or PPPoE bridge (for example ADSL modem).
To enter the PPPoE configuration select the PPPoE menu item. If the Create
PPPoE connection option is selected, the router tries to establish PPPoE connection after
switching-on. PPPoE (Point-to-Point over Ethernet) is a network protocol, which PPP frames
encapsulating to the Ethernet frames. PPPoE client to connect devices that support PPPoE
bridge or a server (typically ADSL router). After connecting the router obtains the IP address
of the device to which it is connected. All communications from the device behind the PPPoE
server is forwarded to industrial router.
Item Description
Username Username for secure access to PPPoE
Password Password for secure access to PPPoE
Authentication Authentication protocol in GSM network
• PAP or CHAP – Router is chosen one of the authentication
methods.
• PAP – It is used PAP authentication method.
• CHAP – It is used CHAP authentication method.
MRU (Maximum Receiving Unit) – it is the identifier of the maximum size
of packet, which is possible to recese in given environment. Default
value is set to 1492 bytes. Other settings may cause incorrect data
transmission.
MTU (Maximum Transmission Unit) – it is the identifier of the maximum size
of packet, which is possible to transfer in given environment. Default
value is set to 1492 bytes. Other settings may cause incorrect data
transmission.
Table 21: PPPoE configuration
Fig. 22: PPPoE configuration
