CONFIGURATION
46
It is possible to send controls SMS in the form:
SMS Description
go online sim 1 Switch to SIM1 card
go online sim 2 Switch to SIM2 card
go online Switch router in online mode
go offline PPP connection termination
set out0=0 Set output I/O connector on 0
set out0=1 Set output I/O connector on 1
set out1=0 Set output expansion port XC-CNT on 0
set out1=1 Set output expansion port XC-CNT on 1
set profile std Set standard profile
set profile alt1 Set alternative profile 1
set profile alt2 Set alternative profile 2
set profile alt3 Set alternative profile 3
reboot Router reboot
get ip Router send answer with IP address SIM card
Table 46: Control SMS
By choosing Enable AT-SMS protocol on expansion port 1 and Baudrate it is
possible to send/receive an SMS on the serial Port 1.
Item Description
Baudrate Communication speed expansion port 1
Table 47: Send SMS on serial PORT1 configuration
By choosing Enable AT-SMS protocol on expansion port 2 and Baudrate it is
possible to send/receive an SMS on the serial Port 2.
Item Description
Baudrate Communication speed expansion port 1
Table 48: Send SMS on serial PORT1 configuration
By choosing Enable AT-SMS protocol on TCP port and enter the TCP port it is
possible to send/receive an SMS on the TCP port. SMS messages are sent by the help
of a standard AT commands.
Item Description
TCP Port TCP port on which will be allowed to send/receive SMS messages.
Table 49: Send SMS on ethernet PORT1 configuration
1.22.1. Send SMS
The SMS is possible to do for example in HyperTerminal program. After establishing
connection with the router via serial interface or Ethernet, it is possible to do with SMS
by the help of the next AT commands.
AT commands Description
AT+CMGF=1 Set the text mode for SMS writing
AT+CMGS=”tel. number” Commands enables to send SMS on entered tel. number
AT+CMGL=ALL List of all SMS messages
AT+CMGR=<index> Read of the definite SMS (all SMS has our index)
AT+CMGD=<index> SMS delete according to index
Table 50: AT commands for work with SMS
