CONFIGURATION

When you select items Use DTR as control of TCP connection is activated function

control TCP connection using signal DTR (CD on the router).

DTR Description server Description client

Active The router allows establishing a TCP

connection.

Router starts TCP connection.

Nonactive The router does not permit establishing

a TCP connection.

Router stops TCP connection.

Table 54: DTR signal description

The changes in settings will apply after pressing the Apply button.

Fig. 50: Expansion port configuration
