Product Specifications
102 Operator’s Manual
Table11-11.Patient Applied and Patient Isolation Risk Current
Patient Applied Risk Current
Condition AC Line Polarity Neutral Line
Power Line
Ground Cable
IEC 60601-1
ANSI/AAMI
ES 60601-1: 2005
Normal Normal Closed Closed 100 µA
Single Fault Open Closed 500 µA
Closed Open
Normal Reversed Closed Closed 100 µA
Single Fault Open Closed 500 µA
Closed Open
Patient Isolation Risk Current
Condition AC Line Polarity Neutral Line
Power Line
Ground Cable
IEC 60601-1
ANSI/AAMI
ES 60601-1: 2005
Single Fault Normal Closed Closed 5000 µA
Reversed Closed Closed
