Covidien Nellcor - Menu Structure; Table 4-1. Menu Structure and Available Options

Menu Options Navigation
Operator’s Manual 29
1. Navigation — Rotate the jog dial clockwise or counter-clockwise until a colored
highlight surrounds the desired area. Any rotation of the jog dial either navigates
or changes the desired option setting.
2. Selection — Press the jog dial to select that desired area, then continue rotating
the jog dial until highlighting the desired menu option, then press again.
The LCD display panel also users with easy-to-read numeric values for patient
oxygen saturation and pulse rate in cyan and yellow, respectively. Reference
Table2-1. on page 2-14.
4.4.1 Menu Structure
Table4-1.Menu structure and available options
Item Available Selections Default
QUICK ACCESS ALARM LIMITS Menus
SpO
2 Menu SatSeconds™ alarm management setting (Off, 10, 25, 50, 100)
Upper (21-100) SpO
2 alarm limit
Lower (20-99) SpO
2 alarm limit
Alarm Inhibition for SpO
2 alarms
100
Depends on
patient
mode. Ref-
erence
Table4-4.
on page 43
PULSE RATE (PR) Menu Upper (30-245) pulse rate alarm limit
Lower (25-240) pulse rate alarm limit
Alarm Inhibition for pulse rate alarms
OPTIONS Menu
VOLUME Alarm Volume (1-8) 5
Key Beep Volume (Off, 1-7) 4
Pulse Volume (Off, 1-7) 4
MODE (Response Mode) Normal, Fast Normal
TREND DATA DOWNLOAD Start (Cancel or Return), Return --
DELETE ALL TREND DATA No, Yes --
SERVICE MENU (For qualified service technicians only) --
ALARM/LIMITS Menu
SpO
2 LIMITS options Upper (21-100) SpO2 alarm limit
Lower (20-99) SpO
2 alarm limit
Alarm Inhibition for SpO
2 alarms
Depends on
patient
mode. Ref-
erence
Table4-4.
on page 43.
PULSE RATE LIMITS options Upper (30-245) pulse rate alarm limit
Lower (25-240) pulse rate alarm limit
Alarm Inhibition for pulse rate alarms
