Product Manual – DOC. 8432A Crestron Pyng OS 2 for CP4-R • 55
The new lighting scene is added to the room under the List of Scenes menu.
NOTE: All of the lighting loads that have been added to the chosen room are added to a
new lighting scene at their current brightness levels. These levels may be adjusted by
tapping the wrench button next to the lighting scene name.
Configure Lighting Scenes
A lighting scene may be configured and tested after it has been added to the system.
Use the
List of Scenes menu to select a lighting scene for configuration.
Light Scenes Screen - List of Scenes Menu
The following configuration options are displayed next to the lighting scene selection:
Tap the play button to recall the lighting scene in real time.
Tap the wrench button to edit the lighting loads that are affected by the scene. A
dialog box for editing scene settings is displayed.
