60 • Crestron Pyng OS 2 for CP4-R Product Manual – DOC. 8432A
The new shade scene is added to the room under the List of Scenes menu.
NOTE: All of the shade groups that have been added to the chosen room are added to a
new shade scene at their current levels. These levels may be adjusted by tapping the
wrench button next to the shade scene name.
Configure Shade Scenes
A shade scene may be configured and tested after it has been added to the system. Use
the
List of Scenes menu to select a shade scene for configuration.
Shade Scenes Screen - List of Scenes Menu
The following configuration options are displayed next to the shade scene selection:
Tap the play button to recall the shade scene in real time.
Tap the wrench button to edit the shade groups that are affected by the scene. A
notice is displayed stating that the shade scene will be recalled upon entering the scene
configuration dialog box. Tap
OK to display the dialog box or tap Cancel to cancel.
