88 • Crestron Pyng OS 2 for CP4-R Product Manual – DOC. 8432A
o Tap the check box next to an action to add or remove that action from the
security event. A checked box indicates that the action is set to occur when
the event is triggered.
o Tap the back arrow (<) next to the room name to return to the Select Room
Below menu.
NOTE: Only rooms that contain selectable actions appear on the Select Room
Below menu. Once an action is selected from a room, the room name is shown
with blue text in the
Select Room Below menu.
Configure Alarms
Select an alarm device from the Select an Item menu to display a configuration screen
for the alarm.
Actions & Events Screen - Dressing Room Alarm 1
Use the alarm configuration screen to associate scenes and other actions with alarm
events.
